38W 115V 60Hz Convection Blower Fan For Pellet Stove And Fireplace

Certification
China Shanghai MH Electric Co., Ltd. certification
China Shanghai MH Electric Co., Ltd. certification
I'm Online Chat Now

38W 115V 60Hz Convection Blower Fan For Pellet Stove And Fireplace

38W 115V 60Hz Convection Blower Fan For Pellet Stove And Fireplace
38W 115V 60Hz Convection Blower Fan For Pellet Stove And Fireplace 38W 115V 60Hz Convection Blower Fan For Pellet Stove And Fireplace 38W 115V 60Hz Convection Blower Fan For Pellet Stove And Fireplace 38W 115V 60Hz Convection Blower Fan For Pellet Stove And Fireplace

Large Image :  38W 115V 60Hz Convection Blower Fan For Pellet Stove And Fireplace

Product Details:
Place of Origin: China
Brand Name: MH motors
Certification: UL
Model Number: MH6029-29038
Payment & Shipping Terms:
Minimum Order Quantity: 320PCS
Price: Negotiable(EXW)
Packaging Details: Standard exporting carton package, ship by sea or airfreight
Delivery Time: 30 work day
Payment Terms: T/T
Supply Ability: 1200pcs/day

38W 115V 60Hz Convection Blower Fan For Pellet Stove And Fireplace

Description
Product Name: 38W 115V 60Hz Convection Blower Fan For Pellet Stove And Fireplace Rated Voltage/Frequency: 115Vac/60Hz
Current(A): 0.8 Input Power(W): 38W
Speed(RPM): 3200±150 Hi-Pot TEST: 1500vac50hz,1Ma,1s
Bearing Type: NMB Ball Bearing Insulation Class: H
Agency: CCC/ETL Thermally Protected: TP
Wind Speed(m/s): ≥10 Air Volume(CFM): 70
Application: OVEN,PELLET STOVE, FIREPLACE
High Light:

NMB Ball Bearing Convection Blower Fan

,

38W convection fan for pellet stove

,

60Hz convection fan for fireplace

38W 115V 60Hz Convection Blower Fan for pellet stove and fireplace



This Convection blower is also referred to as the Room Blower. It blows air through the exhaust plennum and through the openings on the front of the stove to provide the heat to your room. Usually in large air volume, efficient blower, typically used in pellet fireplace, real fire fireplace.





Quick Review:



Product Name: 38W 115V 60Hz Convection Blower Fan For Pellet Stove And Fireplace Rated Voltage/Frequency: 115Vac/60Hz
Current(A): 0.8 Input Power(W): 38W
Speed(RPM): 3200±150 Hi-Pot TEST: 1500vac50hz,1Ma,1s
Bearing Type: NMB Ball Bearing Insulation Class: H
Agency: CCC/ETL Thermally Protected: TP
Wind Speed(m/s): ≥10 Air Volume(CFM): 70
Application: OVEN,PELLET STOVE, FIREPLACE



38W 115V 60Hz Convection Blower Fan For Pellet Stove And Fireplace 0









Production Advantage:



1. 2.38 "high efficiency electrical steel C-FRAME motor

2. Self-cooling fan design, prolong the motor service life.

3. 1.5 inch laminated silicon steel sheet design, high power

4. Volute with flange interface, to meet the different needs of customers

5. Large air volume, unique baffle design of air inlet





CFM Curve for refer:





Stable pressure/air flow characteristic curves, good efficiency and low noise level



38W 115V 60Hz Convection Blower Fan For Pellet Stove And Fireplace 1




Prodcution Package :





38W 115V 60Hz Convection Blower Fan For Pellet Stove And Fireplace 2






FAQ



Q1- What is the warranty of the motors?

The warranty is 18 months from the shipping date.



Q2- Can you design and make the motor as required?

Yes, we provide both ODM and OEM products.



Q3- What is your advantage?

Besides the good quality and the competitive price, we offer the short lead time and quick response.



Q4- What is your terms of payment?
T/T 30% as deposit, and 70% before delivery. The term can be negotiated for long-term business.



Q5- How to get the accurate quotation?

The accurate price will be quoted after the specification and mounting dimension of the motor are checked.



Q6- Do you test all products before the delivery?
Yes, all products are tested OK before the delivery



Q7- Do you have any MOQ for motors?

Usually our MOQ is one pallet. But we accept the small quantity for the trial order.



Q8- Do you have other products?

Yes, besides the shade pole motors and blowers ,we also offer OEM production for some industrial motors such as single phase AC motor, 3 phase industrial motor, stainless steel motor, BLDC fan motor etc... And we offer the sourcing service for other products required.
