3 Speed IP44 115VAC External Rotor Motor Fan Centrifugal Exhaust Fan For Control Cabinet

3 Speed IP44 115VAC External Rotor Motor Fan Centrifugal Exhaust Fan For Control Cabinet
3 Speed IP44 115VAC External Rotor Motor Fan Centrifugal Exhaust Fan For Control Cabinet 3 Speed IP44 115VAC External Rotor Motor Fan Centrifugal Exhaust Fan For Control Cabinet 3 Speed IP44 115VAC External Rotor Motor Fan Centrifugal Exhaust Fan For Control Cabinet 3 Speed IP44 115VAC External Rotor Motor Fan Centrifugal Exhaust Fan For Control Cabinet

Large Image :  3 Speed IP44 115VAC External Rotor Motor Fan Centrifugal Exhaust Fan For Control Cabinet

Product Details:
Place of Origin: China
Brand Name: MH motors
Certification: CE /CCC
Model Number: MH-R2E190-H045-02BT
Payment & Shipping Terms:
Minimum Order Quantity: 200PC2
Price: Negotiable(EXW)
Packaging Details: Standard exporting carton package, ship by sea or airfreight
Delivery Time: 35 work days
Payment Terms: T/T
Supply Ability: 1000PCS/day

3 Speed IP44 115VAC External Rotor Motor Fan Centrifugal Exhaust Fan For Control Cabinet

Description
Product Name: IP44 3-speed 115VAC External Rotor Centrifugal Blower Fan For Air Purifier Or Control Cabinet Motor Type: MH-R2E190-H045-02BT
Rated Voltage/Frequency: 115V60HZ Current(A): H: 0.73 M:0.72 L:0.7
Input Power(W): :H: 80 M:78.8 L:78.5 Output Speed(RPM): H: 3090 M:2826 L:2461
Insulation Class: F Agency: CE
Air Volume(m³/H): H: 327 M:300 L:257 PST: H: 500 M:450 L:400
Noise: H: 68 M:64 L:60 DBA IP: 44
Bearing Type: BALL BEARING Application: Air Purifier/LAB EQUIPMENT
TEMP S: -30℃+60℃
High Light:

3 speed external rotor motor fan

,

IP44 external rotor motor fan

,

115VAC centrifugal exhaust fan

IP44 3-speed 115VAC external rotor Centrifugal Blower fan for air purifier or control cabinet



The blower fan offers three different speed settings, allowing you to adjust the airflow according to your needs. This flexibility is useful in controlling the ventilation or cooling requirements of the air purifier or control cabinet.  IP44 makes it suitable for indoor applications where there may be some exposure to dust or moisture. This blower fan operates on AC power, features an external rotor design, and provides efficient airflow for air purification in air purifier systems.



Quick Review:

Product Name: IP44 3-speed 115VAC External Rotor Centrifugal Blower Fan For Air Purifier Or Control Cabinet Motor Type: MH-R2E190-H045-02BT
Rated Voltage/Frequency: 115V60HZ Current(A): H: 0.73 M:0.72 L:0.7
Input Power(W): :H: 80 M:78.8 L:78.5 Output Speed(RPM): H: 3090 M:2826 L:2461
Insulation Class: F Agency: CE
Air Volume(m³/H): H: 327 M:300 L:257 PST: H: 500 M:450 L:400
Noise: H: 68 M:64 L:60 DBA IP: 44
Bearing Type: BALL BEARING Application: Air Purifier/LAB EQUIPMENT
TEMP S: -30℃+60℃ High Light: IP44 3-speed ,115VAC External Rotor ,Centrifugal Blower Fan ,air Purifier Or Control Cabinet



Can be customized , please contact us to get more information!

3 Speed IP44 115VAC External Rotor Motor Fan Centrifugal Exhaust Fan For Control Cabinet 0





Production Description:



AC MOTOR

Protect method: SELF-RESETTING TOP WIRED INTERNALLY

ROTATION: CW(SEEN FROM ROTOR)

PROTECTION GRADE:IP55

TEMP S:-30℃+60℃

IMPELLER MATERIAL:PA66+25%GF

OPERATION MODE: S1



Air volume/Pressure Curve:


3 Speed IP44 115VAC External Rotor Motor Fan Centrifugal Exhaust Fan For Control Cabinet 1

 3 Speed IP44 115VAC External Rotor Motor Fan Centrifugal Exhaust Fan For Control Cabinet 2

FAQ



Q1- What is the warranty of the motors?

The warranty is 18 months from the shipping date.



Q2- Can you design and make the motor as required?

Yes, we provide both ODM and OEM products.



Q3- What is your advantage?

Besides the good quality and the competitive price, we offer the short lead time and quick response.



Q4- What is your terms of payment?
T/T 30% as deposit, and 70% before delivery. The term can be negotiated for long-term business.



Q5- How to get the accurate quotation?

The accurate price will be quoted after the specification and mounting dimension of the motor are checked.



Q6- Do you test all products before the delivery?
Yes, all products are tested OK before the delivery



Q7- Do you have any MOQ for motors?

Usually our MOQ is one pallet. But we accept the small quantity for the trial order.



Q8- Do you have other products?

Yes, besides the shade pole motors and blowers ,we also offer OEM production for some industrial motors such as single phase AC motor, 3 phase industrial motor, stainless steel motor, BLDC fan motor etc... And we offer the sourcing service for other products required.
