48VDC 105W IP55 Centrifugal Air Blower Fan DC External Rotor

Certification
China Shanghai MH Electric Co., Ltd. certification
China Shanghai MH Electric Co., Ltd. certification
Customer Reviews
For many years we are buying blower fans with MH motor. We are happy to work with them.

—— Roymond

We trust a lot in MH motor! Their motors is the best replacement from FASCO option for us in the market.

—— Edmund Anjum

MH motor is very reliable at product quality and lead time. We have worked with them for 7 years.

—— Abdul Hameed

Motors are running good for my customers' equipment, Very happy to cooperate with MHmotors

—— Roxy Gutierrez

I'm Online Chat Now

48VDC 105W IP55 Centrifugal Air Blower Fan DC External Rotor

48VDC 105W IP55 Centrifugal Air Blower Fan DC External Rotor
48VDC 105W IP55 Centrifugal Air Blower Fan DC External Rotor 48VDC 105W IP55 Centrifugal Air Blower Fan DC External Rotor 48VDC 105W IP55 Centrifugal Air Blower Fan DC External Rotor 48VDC 105W IP55 Centrifugal Air Blower Fan DC External Rotor

Large Image :  48VDC 105W IP55 Centrifugal Air Blower Fan DC External Rotor

Product Details:
Place of Origin: China
Brand Name: MH motors
Certification: CE
Model Number: MH-RIG225-H063-01B
Payment & Shipping Terms:
Minimum Order Quantity: 100PC2
Price: Negotiable(EXW)
Packaging Details: Standard exporting carton package, ship by sea or airfreight
Delivery Time: 35 work days
Payment Terms: T/T
Supply Ability: 1000PCS/day

48VDC 105W IP55 Centrifugal Air Blower Fan DC External Rotor

Description
Product Name: IP55 48VDC 105W Centrifugal Blower Fan-DC External Rotor Rated Voltage/Frequency: 48VDC
Current(A): 4.8 Input Power(W): 105
Output Speed(RPM): 2750 Hi-Pot TEST: 1500vac50hz,3Ma,1s
Insulation Class: F Agency: CE
Air Volume(m³/H): 672 PST: 476pa
Noise: 72dB(A) IP: 55
Bearing Type: BALL BEARING Application: Air Purifier/Control Cabinet/LAB EQUIPMENT
Hgh Light: IP44/ip55, 48VDC 105W Centrifugal Blower Fan,DC External Rotor,air Purifier Or Control Cabinet
High Light:

48VDC outer rotor fan

,

105W IP55 outer rotor fan

,

centrifugal air blower 4.8A

IP55 48VDC 105W Centrifugal Blower fan-DC external rotor

Production Description:

DC MOTOR
Protect method: Polarity Protection;Soft start
Locket-rotor protection
Over current protection
Over voltage protection
Technical features:0-10vdc/pwm speed control
PWM FREQUENCY:1-10KHZ
OPERATION MODE:S1
PROTECTION GRADE:IP44/55
TEMP S:-25℃+60℃
IMPELLER MATERIAL:PA66+25%GF

Quick Review:

Product Name: IP55 48VDC 105W Centrifugal Blower Fan-DC External Rotor Rated Voltage/Frequency: 48VDC
Current(A): 4.8 Input Power(W): 105
Output Speed(RPM): 2750 Hi-Pot TEST: 1500vac50hz,3Ma,1s
Insulation Class: F Agency: CE
Air Volume(m³/H): 672 PST: 476pa
Noise: 72dB(A) IP: 55
Bearing Type: BALL BEARING Application: Air Purifier/Control Cabinet/LAB EQUIPMENT


Can be customized , please contact us to get more information!

48VDC 105W IP55 Centrifugal Air Blower Fan DC External Rotor 0

Air volume/Pressure Curve:

48VDC 105W IP55 Centrifugal Air Blower Fan DC External Rotor 1




FAQ



Q1- What is the warranty of the motors?

The warranty is 18 months from the shipping date.



Q2- Can you design and make the motor as required?

Yes, we provide both ODM and OEM products.



Q3- What is your advantage?

Besides the good quality and the competitive price, we offer the short lead time and quick response.



Q4- What is your terms of payment?
T/T 30% as deposit, and 70% before delivery. The term can be negotiated for long-term business.



Q5- How to get the accurate quotation?

The accurate price will be quoted after the specification and mounting dimension of the motor are checked.



Q6- Do you test all products before the delivery?
Yes, all products are tested OK before the delivery



Q7- Do you have any MOQ for motors?

Usually our MOQ is one pallet. But we accept the small quantity for the trial order.



Q8- Do you have other products?

Yes, besides the shade pole motors and blowers ,we also offer OEM production for some industrial motors such as single phase AC motor, 3 phase industrial motor, stainless steel motor, etc... And we offer the sourcing service for other products required.
