AC 90W Centrifugal Blower Fan 230V 0.41A External Rotor Air Purifier Blower

Certification
China Shanghai MH Electric Co., Ltd. certification
China Shanghai MH Electric Co., Ltd. certification
I'm Online Chat Now

AC 90W Centrifugal Blower Fan 230V 0.41A External Rotor Air Purifier Blower

AC 90W Centrifugal Blower Fan 230V 0.41A External Rotor Air Purifier Blower
AC 90W Centrifugal Blower Fan 230V 0.41A External Rotor Air Purifier Blower AC 90W Centrifugal Blower Fan 230V 0.41A External Rotor Air Purifier Blower AC 90W Centrifugal Blower Fan 230V 0.41A External Rotor Air Purifier Blower AC 90W Centrifugal Blower Fan 230V 0.41A External Rotor Air Purifier Blower

Large Image :  AC 90W Centrifugal Blower Fan 230V 0.41A External Rotor Air Purifier Blower

Product Details:
Place of Origin: China
Brand Name: MH motors
Certification: CE
Model Number: MH-R2E220-H044-01B
Payment & Shipping Terms:
Minimum Order Quantity: 200PC2
Price: Negotiable(EXW)
Packaging Details: Standard exporting carton package, ship by sea or airfreight
Delivery Time: 35 work days
Payment Terms: T/T
Supply Ability: 1000PCS/day

AC 90W Centrifugal Blower Fan 230V 0.41A External Rotor Air Purifier Blower

Description
Product Name: IP44 AC 90W 230V 0.41A External Rotor Centrifugal Blower Fan For Air Purifier Rated Voltage/Frequency: 230V50Hz
Current(A): 0.41 Input Power(W): 90W
Output Speed(RPM): 2500 Hi-Pot TEST: 1800vac50Hz,3mA,1S
Insulation Class: B Agency: CE
Air Volume(m³/H): 535 PST: 475pa
Noise: 75dB(A) IP: 44
Bearing Type: BALL BEARING Application: Air Purifier/LAB EQUIPMENT
Hgh Light: IP44 AC 90W 230V 0.41A, External Rotor ,Centrifugal Blower Fan ,for Air Purifier
High Light:

AC 90W Centrifugal Blower Fan

,

Centrifugal Blower Fan 230V

,

0.41A air purifier blower

IP44 AC 90W 230V 0.41A external rotor Centrifugal Blower fan for air purifier



The blower fan is AC with IP44, it was specifically designed for use in air purifiers or lab equipment. Air purifiers are devices that remove contaminants, such as dust, pollen, and smoke particles, from the air.



This blower fan operates on AC power, features an external rotor design, and provides efficient airflow for air purification in air purifier systems.



Quick Review:

Product Name: IP44 AC 90W 230V 0.41A External Rotor Centrifugal Blower Fan For Air Purifier Rated Voltage/Frequency: 230V50Hz
Current(A): 0.41 Input Power(W): 90W
Output Speed(RPM): 2500 Hi-Pot TEST: 1800vac50Hz,3mA,1S
Insulation Class: B Agency: CE
Air Volume(m³/H): 535 PST: 475pa
Noise: 75dB(A) IP: 44
Bearing Type: BALL BEARING Application: Air Purifier/LAB EQUIPMENT



Can be customized , please contact us to get more information!

AC 90W Centrifugal Blower Fan 230V 0.41A External Rotor Air Purifier Blower 0





Production Description:



1. Powered by outer rotor motor

2. Protect method: Over-heat thermal protection

3. TEMP S:-20℃+60℃

4. IMPELLER MATERIAL:PA66+25%GF

5. Protection Grade: IP44



Air volume/Pressure Curve:



AC 90W Centrifugal Blower Fan 230V 0.41A External Rotor Air Purifier Blower 1




AC 90W Centrifugal Blower Fan 230V 0.41A External Rotor Air Purifier Blower 2





FAQ



Q1- What is the warranty of the motors?

The warranty is 18 months from the shipping date.



Q2- Can you design and make the motor as required?

Yes, we provide both ODM and OEM products.



Q3- What is your advantage?

Besides the good quality and the competitive price, we offer the short lead time and quick response.



Q4- What is your terms of payment?
T/T 30% as deposit, and 70% before delivery. The term can be negotiated for long-term business.



Q5- How to get the accurate quotation?

The accurate price will be quoted after the specification and mounting dimension of the motor are checked.



Q6- Do you test all products before the delivery?
Yes, all products are tested OK before the delivery



Q7- Do you have any MOQ for motors?

Usually our MOQ is one pallet. But we accept the small quantity for the trial order.



Q8- Do you have other products?

Yes, besides the shade pole motors and blowers ,we also offer OEM production for some industrial motors such as single phase AC motor, 3 phase industrial motor, stainless steel motor, BLDC fan motor etc... And we offer the sourcing service for other products required.
