39W 0.7A Air Convection Blower Motor 60Hz Ac Blower Motor For Fireplace

Certification
China Shanghai MH Electric Co., Ltd. certification
China Shanghai MH Electric Co., Ltd. certification
I'm Online Chat Now

39W 0.7A Air Convection Blower Motor 60Hz Ac Blower Motor For Fireplace

39W 0.7A Air Convection Blower Motor 60Hz Ac Blower Motor For Fireplace
39W 0.7A Air Convection Blower Motor 60Hz Ac Blower Motor For Fireplace 39W 0.7A Air Convection Blower Motor 60Hz Ac Blower Motor For Fireplace 39W 0.7A Air Convection Blower Motor 60Hz Ac Blower Motor For Fireplace 39W 0.7A Air Convection Blower Motor 60Hz Ac Blower Motor For Fireplace

Large Image :  39W 0.7A Air Convection Blower Motor 60Hz Ac Blower Motor For Fireplace

Product Details:
Place of Origin: China
Brand Name: MH motors
Certification: UL
Model Number: MH6019-19600
Payment & Shipping Terms:
Minimum Order Quantity: 500PCS
Price: Negotiable(EXW)
Packaging Details: Standard exporting carton package, ship by sea or airfreight
Delivery Time: 30 work days
Payment Terms: T/T
Supply Ability: 1200PCS/day

39W 0.7A Air Convection Blower Motor 60Hz Ac Blower Motor For Fireplace

Description
Product Name: AC 39W 0.7A High Efficiency Air Convection Blower Motor For Fireplace Motor Type: MH6019-19600
Rated Voltage/Frequency: 120V60Hz Current(A): 0.7
Input Power(W): 40 Speed(RPM): 2778
Air Flow(CFM): 96 Wind Speed(m/s): 12
Bearing Type: NMB Ball Bearing Insulation Class: H
Protection Method: TP(THERMAL PROTECTOR) Hi-Pot TEST: 1500vac1mA,1S
Safe Certification: UL Application: Fireplace
High Light: AC Shade Pole ,39W 0.7A ,High Efficiency ,Air Convection Blower Motor , Fireplace
High Light:

39W Convection Blower Motor

,

0.7A Air Convection Blower Motor

,

60Hz ac blower motor for fireplace

AC 39W 0.7A High Efficiency Air Convection Blower Motor for fireplace



The Air convection blower motor is designed to be highly efficient, meaning it converts a significant portion of the electrical energy into mechanical energy without excessive energy loss. This efficiency helps to optimize the performance of the motor and minimize energy consumption.



Fireplaces provide heating and ambiance to a room by burning fuel, such as wood or gas. The motor's role is to enhance the circulation of warm air generated by the fireplace, ensuring efficient heat distribution throughout the space.



Quick Review:

Product Name: AC 39W 0.7A High Efficiency Air Convection Blower Motor For Fireplace Motor Type: MH6019-19600
Rated Voltage/Frequency: 120V60Hz Current(A): 0.7
Input Power(W): 40 Speed(RPM): 2778
Air Flow(CFM): 96 Wind Speed(m/s): 12
Bearing Type: NMB Ball Bearing Insulation Class: H
Protection Method: TP(THERMAL PROTECTOR) Hi-Pot TEST: 1500vac1mA,1S
Safe Certification: UL Application: Fireplace

39W 0.7A Air Convection Blower Motor 60Hz Ac Blower Motor For Fireplace 0

Production Description:



1. The blower is 100% ball bearing

2. Be powered by C-Frame shaded pole motor, high efficiency.

3. Superbly Balanced.

4. Long Lasting

5. Special bracket design, better stable.

6. Class H grade



Air Flow Curve:
 39W 0.7A Air Convection Blower Motor 60Hz Ac Blower Motor For Fireplace 1



A higher flowing blower,Heats large rooms effectively.



39W 0.7A Air Convection Blower Motor 60Hz Ac Blower Motor For Fireplace 2

FAQ



Q1- What is the warranty of the motors?

The warranty is 18 months from the shipping date.



Q2- Can you design and make the motor as required?

Yes, we provide both ODM and OEM products.



Q3- What is your advantage?

Besides the good quality and the competitive price, we offer the short lead time and quick response.



Q4- What is your terms of payment?
T/T 30% as deposit, and 70% before delivery. The term can be negotiated for long-term business.



Q5- How to get the accurate quotation?

The accurate price will be quoted after the specification and mounting dimension of the motor are checked.



Q6- Do you test all products before the delivery?
Yes, all products are tested OK before the delivery



Q7- Do you have any MOQ for motors?

Usually our MOQ is one pallet. But we accept the small quantity for the trial order.



Q8- Do you have other products?

Yes, besides the shade pole motors and blowers ,we also offer OEM production for some industrial motors such as single phase AC motor, 3 phase industrial motor, stainless steel motor, BLDC fan motor etc... And we offer the sourcing service for other products required.



Thank you very much for viewing this page
Sincerely looking forward to our cooperation!
