43W 0.62A Cross Flow Blower Fan C Frame Shaded Pole Fan Motor 2300RPM

43W 0.62A Cross Flow Blower Fan C Frame Shaded Pole Fan Motor 2300RPM
43W 0.62A Cross Flow Blower Fan C Frame Shaded Pole Fan Motor 2300RPM 43W 0.62A Cross Flow Blower Fan C Frame Shaded Pole Fan Motor 2300RPM 43W 0.62A Cross Flow Blower Fan C Frame Shaded Pole Fan Motor 2300RPM 43W 0.62A Cross Flow Blower Fan C Frame Shaded Pole Fan Motor 2300RPM

Large Image :  43W 0.62A Cross Flow Blower Fan C Frame Shaded Pole Fan Motor 2300RPM

Product Details:
Place of Origin: China
Brand Name: MH motors
Certification: UL
Model Number: MH6029-29462(60x300mm)
Payment & Shipping Terms:
Minimum Order Quantity: 500PCS
Price: Negotiable(EXW)
Packaging Details: Standard exporting carton package, ship by sea or airfreight
Delivery Time: 30 work days
Payment Terms: T/T
Supply Ability: 1500PCS/day

43W 0.62A Cross Flow Blower Fan C Frame Shaded Pole Fan Motor 2300RPM

Description
Product Name: 43W 0.62A AC Cross Flow Blowers Fan With C Frame Rated Voltage/Frequency: 120Vac/60Hz
Current(A): 0.62 Input Power(W): 43W
Motor Type: AC Shade Pole Motors Speed(RPM): 2300
Hi-Pot TEST: 1800vac50hz,3Ma,1s Bearing Type: NMB Ball Bearing
Insulation Class: H Agency: UL
Thermally Protected: Yes Wind Speed(m/s): 7
Air Volume(CFM): 170 Application: Pellet Stove,oven
High Light:

43W Cross Flow Blower Fan

,

0.62A Cross Flow Blower Fan

,

c frame shaded pole fan motor

China 43W 0.62A AC Cross flow Blowers Fan with C frame shade pole UL agency



The cross flow blower fan has a power input of 43 watts and operates at a current of 0.62A, providing sufficient airflow for its intended applications.The fan is equipped with a C frame shade pole motor, known for its reliability and durability. This type of motor provides consistent and stable performance which allows for a wider and more uniform distribution of airflow. It is suitable for applications that require a continuous and even stream of air.



Quick Review:


Model Type:MH6029-29462 (60x300mm)

Motor Type:AC Shade Pole Motor

Rated Voltage/Frequency 120Vac/60Hz Hi-Pot TEST 1500vac50hz,1Ma,1s
Current(A) 0.62 Bearing Type NMB Ball Bearing
Input Power(W) 43 Insulation Class H (Thermally Protected)
Speed(RPM) 2300 Agency Certification UL
Wind Speed(m/s) 7 Air Volume(CFM) 170
Feature with Cframe shade pole motor  Application  Pellet Stove/stove



43W 0.62A Cross Flow Blower Fan C Frame Shaded Pole Fan Motor 2300RPM 0

Production Feature :
1. A 60mm x 300mm impeller, delivering high airflow with low noise levels.
2. Innovative air flow system design that reduces overall system costs and simplifies the overall structure.
3. Applicable in various fields, including food heating and fireplaces.
4. Driven by a C-FRAME shaded pole motor.
5. The motor can be mounted in any of the four positions.
6. Utilizes ball bearing structure, suitable for high-temperature environments and offering a long lifespan.
7. Multiple performance options available for selection.


AIR FLOW  CURVE

 43W 0.62A Cross Flow Blower Fan C Frame Shaded Pole Fan Motor 2300RPM 1





Shanghai MH Electric Co., Ltd, located in SHANGHAI, has been specialize in the field of exporting Shade Pole Motors & blowers for several years. We have our own production facility and a strong R&D team.

The MH crossflow blower makes the air in the box evenly distributed in every corner.

Welcome your business chat and visit.

FAQ



Q1- What is the warranty of the motors?

The warranty is 18 months from the shipping date.



Q2- Can you design and make the motor as required?

Yes, we provide both ODM and OEM products.



Q3- What is your advantage?

Besides the good quality and the competitive price, we offer the short lead time and quick response.



Q4- What is your terms of payment?
T/T 30% as deposit, and 70% before delivery. The term can be negotiated for long-term business.



Q5- How to get the accurate quotation?

The accurate price will be quoted after the specification and mounting dimension of the motor are checked.



Q6- Do you test all products before the delivery?
Yes, all products are tested OK before the delivery



Q7- Do you have any MOQ for motors?

Usually our MOQ is one pallet. But we accept the small quantity for the trial order.



Q8- Do you have other products?

Yes, besides the shade pole motors and blowers ,we also offer OEM production for some industrial motors such as single phase AC motor, 3 phase industrial motor, stainless steel motor, BLDC fan motor etc... And we offer the sourcing service for other products required.
