2.38"18W C Frame Electric Fan Motors Ac Shaded Pole For Kitchen Blender

Certification
China Shanghai MH Electric Co., Ltd. certification
China Shanghai MH Electric Co., Ltd. certification
I'm Online Chat Now

2.38"18W C Frame Electric Fan Motors Ac Shaded Pole For Kitchen Blender

2.38"18W C Frame Electric Fan Motors Ac Shaded Pole For Kitchen Blender
2.38"18W C Frame Electric Fan Motors Ac Shaded Pole For Kitchen Blender 2.38"18W C Frame Electric Fan Motors Ac Shaded Pole For Kitchen Blender 2.38"18W C Frame Electric Fan Motors Ac Shaded Pole For Kitchen Blender

Large Image :  2.38"18W C Frame Electric Fan Motors Ac Shaded Pole For Kitchen Blender

Product Details:
Place of Origin: China
Brand Name: MH motors
Certification: ETL/UL
Model Number: MH6029-29053
Payment & Shipping Terms:
Minimum Order Quantity: 480PCS
Price: Negotiable(EXW)
Packaging Details: Standard exporting carton package, ship by sea or airfreight
Delivery Time: 30 work days
Payment Terms: T/T
Supply Ability: 3000PCS/day

2.38"18W C Frame Electric Fan Motors Ac Shaded Pole For Kitchen Blender

Description
Product Name: China 2.38" 18W C Frame Electric Fan Motors Ac Shaded Pole Motor Type: MH6029-29053
Rated Voltage/Frequency: 115Vac/60Hz Current(A): 0.29A
Input Power(W): 18W Output Speed(RPM): 3500
Hi-Pot TEST: 1500vac50hz,1Ma,1s Bearing Type: NMB BALL BEARING
Insulation Class: H Agency: ETL/UL
Protect Method: TP Application: Kitchen Machine
High Light: China 2.38", 18W 0.29A 115VAC 60Hz, C Frame Motor ,AC Shade Pole
High Light:

18W Electric Fan Motors

,

Kitchen blender Electric Fan Motors

,

Ac Shaded Pole Electric Fan Motors

China 2.38" 18W 0.29A 115VAC C Frame Motor AC Shade Pole




 Can be customized according to customer requirements, please contanct us.





Stack Length (L) (mm/inch) Voltage (V) Frequency (Hz) Speed(RPM) Max Torque(Oz.in) Max HP
Output
9.53(3/8) 110-120
220-240
50/60 3000 1.4 1/225
12.50(1/2) 3000 3.1 1/112
15.63(5/8) 3000 4.3 1/90
18.75(3/4) 3000 6 1/60
21.88(7/8) 3000 7.5 1/45
25.40(1) 3000 9.3 1/40
28.123(1 1/8) 3000 11.2 1/30
34.93(1 3/8) 3000 16 1/25
38.10(1 1/2) 3000 18.5 1/18
50.80(2) 3000 24.8 1/13



2.38"18W C Frame Electric Fan Motors Ac Shaded Pole For Kitchen Blender 0




Production Feature :


2.38’’ C-FRAME MOTOR

Heavy-duty steel and die-cast construction

Several shaft size options

Several mounting options available

Several lead configurations available

Ball bearing or Sleeve bearing available




Performance Curve

2.38"18W C Frame Electric Fan Motors Ac Shaded Pole For Kitchen Blender 1






FAQ

Q1- What is the warranty of the motors?

The warranty is 18 months from the shipping date.



Q2- Can you design and make the motor as required?

Yes, we provide both ODM and OEM products.



Q3- What is your advantage?

Besides the good quality and the competitive price, we offer the short lead time and quick response.



Q4- What is your terms of payment?
T/T 30% as deposit, and 70% before delivery. The term can be negotiated for long-term business.



Q5- How to get the accurate quotation?

The accurate price will be quoted after the specification and mounting dimension of the motor are checked.



Q6- Do you test all products before the delivery?
Yes, all products are tested OK before the delivery



Q7- Do you have any MOQ for motors?

Usually our MOQ is one pallet. But we accept the small quantity for the trial order.



Q8- Do you have other products?

Yes, besides the shade pole motors and blowers ,we also offer OEM production for some industrial motors such as single phase AC motor, 3 phase industrial motor, stainless steel motor, BLDC fan motor etc... And we offer the sourcing service for other products required.
