82W 0.7A C Frame Motor AC Single Phase Shaded Pole Induction Motor For Gas Detection Pump

Certification
China Shanghai MH Electric Co., Ltd. certification
China Shanghai MH Electric Co., Ltd. certification
I'm Online Chat Now

82W 0.7A C Frame Motor AC Single Phase Shaded Pole Induction Motor For Gas Detection Pump

82W 0.7A C Frame Motor AC Single Phase Shaded Pole Induction Motor For Gas Detection Pump
82W 0.7A C Frame Motor AC Single Phase Shaded Pole Induction Motor For Gas Detection Pump 82W 0.7A C Frame Motor AC Single Phase Shaded Pole Induction Motor For Gas Detection Pump 82W 0.7A C Frame Motor AC Single Phase Shaded Pole Induction Motor For Gas Detection Pump 82W 0.7A C Frame Motor AC Single Phase Shaded Pole Induction Motor For Gas Detection Pump

Large Image :  82W 0.7A C Frame Motor AC Single Phase Shaded Pole Induction Motor For Gas Detection Pump

Product Details:
Place of Origin: China
Brand Name: MH motors
Certification: ETL/CE/CCC
Model Number: MH6038-38260
Payment & Shipping Terms:
Minimum Order Quantity: 600PCS
Price: Negotiable(EXW)
Packaging Details: Standard exporting carton package, ship by sea or airfreight
Delivery Time: 30 work days
Payment Terms: T/T
Supply Ability: 3000PCS/day

82W 0.7A C Frame Motor AC Single Phase Shaded Pole Induction Motor For Gas Detection Pump

Description
Product Name: China 82W 0.7A C Frame Motor AC Single Phase Shade Pole For Gas Detection Pump Motor Type: MH6038-38260
Rated Voltage/Frequency: 230Vac/60Hz Current(A): 0.7
Input Power(W): 82 Output Speed(RPM): 3000
Hi-Pot TEST: 1800vac50hz,3Ma,1s Bearing Type: SLEEVE BEARING
Insulation Class: H Agency: CE/CCC/ETL
START TORQUE: @198V:48MN.M Protect Method: TP
Application: PUMP;Gas Detection Pump High Light: 82W 0.7A C Frame Motor ,AC Single Phase Shade Pole, FGas Detection Pump
High Light:

82W C Frame Motors

,

0.7A C Frame Motors

,

shaded pole induction motor

China 82W 0.7A C Frame Motor AC Single Phase Shade Pole for Gas detection pump


This C frame motor is specifically designed to drive gas detection pumps used for gas detection and measurement purposes. The motor operates with a power rating of 82 watts, providing efficient energy conversion for the gas detection pump. With a current rating of 0.7 amperes, the motor ensures reliable and consistent performance during operation.



Product parameter table:



Stack Length (L) (mm/inch) Voltage (V) Frequency (Hz) Speed(RPM) Max Torque(Oz.in) Max HP
Output
21.88(7/8) 110-120V/220-240V 50/60 3000 7.5 1/45
25.40(1) 3000 9.3 1/40
28.123(1 1/8) 3000 11.2 1/30
34.93(1 3/8) 3000 16 1/25
38.10(1 1/2) 3000 18.5 1/18
50.80(2) 3000 24.8 1/13


Note: Can be customized according to customer requirements, please contanct us.



82W 0.7A C Frame Motor AC Single Phase Shaded Pole Induction Motor For Gas Detection Pump 0


Production Feature :



1. 2.38’’ C-FRAME MOTOR

2. Heavy-duty steel and die-cast construction

3. Several shaft size options

4. Several mounting options available

5. Several lead configurations available

6. Ball bearing or Sleeve bearing available

7. Application:  Gas detection pump



82W 0.7A C Frame Motor AC Single Phase Shaded Pole Induction Motor For Gas Detection Pump 1



Torque Curve
82W 0.7A C Frame Motor AC Single Phase Shaded Pole Induction Motor For Gas Detection Pump 2
